1005262 GA03-P Spare Parts Powder Coating Machine GA03-P Filter Element

Brand Name : Astar

Model Number : 1005 262

Certification : CE, ISO9001

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 5 - 8 work days

Packaging Details : Carton

Product name : GA03-P Filter element

Customized support : OEM

Length : 22 mm

Grade : Industrial

Video Outgoing-inspection : Provided

Inner diameter : 9 mm

External diameter : 14 mm

Contact Now

GA03-P Filter element 1005 262 GA03-P Spare Parts Powder Coating Machine GA03-P

Product Description

GA03-P Filter element 1005 262.It more suitable for profiles or flat parts powder coating. The size and material can completely work with Gema GA03 and GM03 electrostatic powder coating guns.

Product Features
*Brand
Astar
*Name

1005262 GA03-P Spare Parts Powder Coating Machine GA03-P Filter element
*Color
White
*Length
22 mm
*Customized support
OEM
*Color
white
*Inner diameter
9 mm
*External diameter
14 mm

1005262 GA03-P Spare Parts Powder Coating Machine GA03-P Filter Element1005262 GA03-P Spare Parts Powder Coating Machine GA03-P Filter Element

1005262 GA03-P Spare Parts Powder Coating Machine GA03-P Filter Element

1005262 GA03-P Spare Parts Powder Coating Machine GA03-P Filter Element

GM03 –Spare parts list
GM03 manual powder gun –complete
A
negative polarity, incl. gun cable –6 m, rinsing air hose –6 m, flat jet nozzle, brush and parts kit, without powder hose
1008 070
GM03 manual powder gun –complete
1008 073
positive polarity, incl. gun cable –6 m, rinsing air hose –6 m, flat jet nozzle, brush and parts kit, without powder hose
B
Manual powder gun shaft OptiSelect GM03 (incl. cascade) with:
Gun cable 2 m, negative polarity (–)
1007 971
Gun cable 6 m, negative polarity (–)
1007 972
Gun cable 12 m, negative polarity (–)
1007 973
Gun cable 2 m, positive polarity (+)
1007 974
Gun cable 6 m, positive polarity (+)
1007 975
Gun cable 12 m, positive polarity (+)
1007 968
1
Gun body
1007 220
2
Cascade –complete, negative polarity
1007 231
Cascade –complete, positive polarity
1007 232
3
Print holder –complete
1007 216
4
End plate with hook
1007 217
5
Grip –complete (incl. pos. 5.1 and 5.2)
1007 961
5.1
Grub screw –M3x8 mm
1008 157
5.2
Grip sealing
1007 633
6
Trigger –complete
1007 213
7
Trigger cover
1007 212
8
Countersunk-head screw –M4x6 mm
1000 845
9
SuperCorona connection
1007 238
10
Gun cable 2 m –complete
1007 963
Gun cable 6 m –complete
1007 964
Gun cable 12 m –complete
1007 965
11
Rinsing air connection
1000 804
11.1
Rinsing air hose
100 854*
12
Powder tube –complete
1007 958 #
13
Compression spring
1001 488
14
Clip ring
1007 960
15
Hose connection Ø 11-12 mm –complete (incl. pos 15.1)
1001 340 #
Hose connection Ø 9-10 mm –complete (incl. pos 15.1)
1002 030 #
15.1
O-ring for pos. 15
1000 822 #
16
Threaded sleeve (see corresponding spare parts list)
18
Cascade space gasket
1007 635#
Cleaning brush –Ø 12 mm
389 765
Parts set (not shown), consisting of:
1008302
Flat jet nozzle NF21
1007 935#
Adapter NF08
1003634#
Cable clamp
303 070
Hose connector –complete, for hose interior Ø 9-10mm
1002030
1
Corona PC05
1008 165#
NF20 Profiles/flat parts (standard nozzle)
1010 090
NF27 Profiles/flat parts
1010 752
NF21 Complex profiles and depressions
1007 935
NF22 Complex parts (deep recess), target spraying
1008 145
NF24 Large surfaces
1008 147
electrode
1007 683
NF20 flat nozzle complete
1010 160
NF27 flat nozzle complete
1010 754
NF21 flat nozzle complete
1007 932
NF22 flat nozzle complete
1008 140
NF24 Large surfaces
1008 142
Threaded sleeve
1008 326
Threaded sleeve
1007 229
NS04 Round jet nozzle
1008 151
round electrode
1008 152
Round jet nozzle complete
1008 150
Threaded sleeve
1007 229
Deflectors Ø 16mm
331 341
Deflectors Ø 24 mm
331 333
Deflectors Ø 32 mm
331 325
Deflectors Ø 50 mm
345 822
Gun extensions without nozzle L = 150 mm
1008 616
Gun extensions without nozzle L = 150 mm
1007 718
Gun extensions with Flat jet nozzle NF25 L = 150 mm
1007 746
Gun extensions with Round jet nozzle NS09 L = 150 mm
1007 748
Gun extensions without nozzle L = 300 mm
1008 617
Gun extensions without nozzle L = 300 mm
1007 719
Gun extensions with Flat jet nozzle NF25 L = 300 mm
1007 747
Gun extensions with Round jet nozzle NS09 L = 300 mm
1007 749
NF25 Profiles/flat parts
1007 735
NF26 Complex profiles and depressions
1007 742
NS09 Suitable for large surfaces
1008 257
Electrode
1007 684
Electrode
1008 258
NF25 flat nozzle complete
1007 743
NF26 flat nozzle complete
1007 744
NS09 round nozzle complete
1008 259
Threaded sleeve
1007 740
POE Antistatic powder hoses Ø 11/16 mm
105 139
POE Antistatic powder hoses Ø 12/18 mm
1001 674
POE Antistatic powder hoses Ø 10/15 mm
1001 673
Powder cup 500 ml
1002 069

Company introduction

Astar Machinery Co., Ltd. is a comprehensive service in production, R&D; and sales, operates mainly in electrostatic spraying equipment, including electrostatic dust elimination equipment; electrostatic flocking machine, electrostatic powder spraying machine, electrostatic liquid spray machine, electrostatic spraying gun, high voltage module, circuit board, powder barrel, powder tube, cable, reciprocator, spraying room, control cabinet, oven, vibration sieve, air shower, gun shell, venturi tube, powder pump, deflector, nozzle, electrode holder and other products. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in electrostatic powder coating and other industries.

Our products are widelyrecognized and trusted by users and can meet continuously changing economic and social needs. We welcome new and old customersfrom all walks of life to contact us for future business relationships and mutual success!
